Designed to go anywhere, ride everywhere, and do it all with ease. Thunderbolt SL provides all of the trail manners that Fat Bikes are known for, while seamlessly accommodating Demons Turbo Technology. Its lightweight aluminum alloy frame and advanced MOZO suspension makes this modern fat bike agile, and versatile. Paired with Bafangs 500W Motor and Samsungs 48V / 16.75AH battery, Thunderbolt SL will allow you to ride hard on the trails without worrying about recharging for up to 60 km/ 37 mi.
- Motor: 500W Rear Mounted Brushless Motor
- Range: 50 km - 60 km/31 mi - 37 mi
- Battery: 48V/16.75Ah Removable Li-ion Battery
- Brake: Tektro (HD-E350) Hydraulic Disc Brake
- Tires: Kenda 26" x 4" K1151
- Weight Limit: 331 lbs
English Installation Manual (PDF)
PEB-01-14 | PEB-01-13 | PEB-01-01
POWER
Motor: 500W Bafang Rear Mounted Brushless Motor
Range: 50 km - 60 km
Battery: 16.75Ah / 48V Removable Li-ion Battery
Charger: AC 100V-240V 2 amps
SPEED
Drive Mode: Cadence Sensing Pedal Assist, Trigger Throttle
Pedal Assist: 0-9 Levels
Top Speed: 32 km/h
Brake: Tektro (HD-E350) Hydraulic Disc Brakes
Derailleur: Shimano Tourney 7 Speed
Shift: Shimano 7 Speed
Gears: Shimano’s Tourney 7 Speed
COMPONENTS
Frame: Aluminum Alloy
Suspension: Mozo Suspension Fork
Weight: 29 kg / 64 lbs
Wheels: 26’’
Chain: KMC Chain
Cranks: 48T Chainring
Weight Limit: 150 kg / 331 lbs
Lights: Battery Powered Front Light, Seatpost Mounted Rear Light
Handlebars: Promax Handlebars
Tires: Kenda 26" x 4" K1151
Min. Seat Height: 77 cm
Motor Placement: Rear
Display: LCD Color Display
Description
Designed to go anywhere, ride everywhere, and do it all with ease. Thunderbolt SL provides all of the trail manners that Fat Bikes are known for, while seamlessly accommodating Demons Turbo Technology. Its lightweight aluminum alloy frame and advanced MOZO suspension makes this modern fat bike agile, and versatile. Paired with Bafangs 500W Motor and Samsungs 48V / 16.75AH battery, Thunderbolt SL will allow you to ride hard on the trails without worrying about recharging for up to 60 km/ 37 mi.
- Motor: 500W Rear Mounted Brushless Motor
- Range: 50 km - 60 km/31 mi - 37 mi
- Battery: 48V/16.75Ah Removable Li-ion Battery
- Brake: Tektro (HD-E350) Hydraulic Disc Brake
- Tires: Kenda 26" x 4" K1151
- Weight Limit: 331 lbs
English Installation Manual (PDF)
PEB-01-14 | PEB-01-13 | PEB-01-01
Features
POWER
Motor: 500W Bafang Rear Mounted Brushless Motor
Range: 50 km - 60 km
Battery: 16.75Ah / 48V Removable Li-ion Battery
Charger: AC 100V-240V 2 amps
SPEED
Drive Mode: Cadence Sensing Pedal Assist, Trigger Throttle
Pedal Assist: 0-9 Levels
Top Speed: 32 km/h
Brake: Tektro (HD-E350) Hydraulic Disc Brakes
Derailleur: Shimano Tourney 7 Speed
Shift: Shimano 7 Speed
Gears: Shimano’s Tourney 7 Speed
COMPONENTS
Frame: Aluminum Alloy
Suspension: Mozo Suspension Fork
Weight: 29 kg / 64 lbs
Wheels: 26’’
Chain: KMC Chain
Cranks: 48T Chainring
Weight Limit: 150 kg / 331 lbs
Lights: Battery Powered Front Light, Seatpost Mounted Rear Light
Handlebars: Promax Handlebars
Tires: Kenda 26" x 4" K1151
Min. Seat Height: 77 cm
Motor Placement: Rear
Display: LCD Color Display
